12v Hydraulic Power Unit

The hydraulic power unit is an independent power system in hydraulic machinery. It is used as an oil supply device and is connected to several hydraulic cylinders through an external pipeline system to control multiple sets of valve actions. Its construction usually includes a fluid reservoir, pump and motor. Its job is to apply the hydraulic pressure required to drive motors, cylinders, actuators and other hydraulic system components.

1) Piston type

Single piston rod hydraulic cylinder has a piston rod at only one end. As shown in the figure, it is a single-piston hydraulic cylinder. The inlet and outlet oil ports A and B at both ends can pass pressure oil or return oil to realize two-way movement, so it is called double-acting cylinder.

2) Plunger type

Plunger hydraulic cylinder is a single-acting hydraulic cylinder. It can only move in one direction by hydraulic pressure. The return stroke of the plunger depends on other external forces or the weight of the plunger.

3) Telescopic type

The telescopic hydraulic cylinder has two-stage or multi-stage pistons. The sequence of piston extension in the telescopic hydraulic cylinder is from large to small, while the sequence of no-load retraction is generally from small to large. The telescopic cylinder can achieve a long stroke, while the length is shorter when retracting, and the structure is relatively compact. This hydraulic cylinder is often used in construction machinery and agricultural machinery.

4) Swing type

Swing hydraulic cylinder is an executive component that outputs torque and realizes reciprocating motion, also known as swing hydraulic motor. There are two forms: single leaf and double leaf. The stator block is fixed on the cylinder block, and the blades and rotors are connected together. According to the oil inlet direction, the blade will drive the rotor to swing back and forth.

All parameters can be customized

Parameters of the sample

1)Natural cooling: cooling by the tank itself and air heat exchange, generally used for tank capacity less than 250 L system.
2) Forced cooling: The cooler is used for forced cooling, which is generally used for systems with tank capacity greater than 250 L. The main technical parameters of hydraulic station are the effective storage of oil tank and motor power. There are 18 specifications of fuel tank capacity (unit: L): 25, 40, 63, 100, 160, 250, 400, 630, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6000 This series of hydraulic station according to user requirements and working conditions, can do :① according to the system configuration integrated block, No integration blocks; (2) can be set cooler, heater, accumulator; (3) 3)Electrical control can be set up, but also without electrical control device.

As a leader in hydraulic cylinder design, manufacturing and customized processing with more than 25 years of history, HCIC has more than 700 employees and more than 100000 square meters of manufacturing plant. The company has professional departments such as hydraulic cylinder design, sales, production and quality inspection. HCIC hydraulic cylinder products mainly include manufacturing engineering machinery, loader hydraulic cylinder, vehicle hydraulic cylinder, hydraulic system and air control system. It can also manufacture large, non-standard and different types of cylinders. All of our hydraulic cylinders are made of high-quality raw materials, through strict professional technology and quality assurance.

1.Whether you could make our brand on your products?

A:Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.

2.Whether you could make your products by our color?

A:Yes, The color of products can be customized if you can meet our MOQ.

3.How to guarantee the quality of your products?

A:1) Strict detection during production.

2) Strict sampling inspection on products before shipment and intact product packaging ensured.

4.How about your delivery time?

A:Generally, it will take 25 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

5.Can you produce according to the samples?

A:Yes, we can produce by your samples or technical drawings.

6.Do you test all your goods before delivery?

A:Yes, we have 100% test before delivery.
